Hardware pressed, kitted and labeled to your BOM.
Self-clinching nuts, studs and standoffs pressed on an auto-feed press, then kitted, bagged and labeled to your bill of materials, up to 40 lines a kit.
- 6 T
- #4 TO 3/8 IN
- 40
- 6 t, auto-feedFW-M13
- 18 inreaches the middle of a 2U chassis
- #4 to 3/8 innuts, studs and standoffs
- 0.040 to 0.250 inchecked against the fastener maker's minimum
- Up to 40 linesbagged and labeled to your BOM
- Your part number and revon every bag
FIG. 02.6 / FW-M13, PRESSING BEFORE FINISH
Tolerances, without a callout.
Tighter is possible by quote. Put it on the print and the estimator prices the inspection it needs.
| Feature | Tolerance | Note |
|---|---|---|
| Pressed hardware flush | Within 0.005 in | checked on the first part |
| Push-out | Per the fastener maker's rating | sampled per lot |
| Thread fit after finish | GO and NO-GO | powder masked out of threads |
| Kit count | 100 percent | counted twice, by two people |
What runs on this line.
Outside these bars is a conversation, not a no. Call the quote desk with the grade and the thickness.
Check a material against every machineHardware and assembly, step by step.
- Press
Nuts and studs go in after forming, before finish, so the powder cannot crack around them.
- Check
The first part is checked for flush and thread fit before the lot.
- Kit
Hardware is counted, bagged and labeled with your part number and rev.
The tags on your traveler.
Three changes that lower the price.
Hardware too close to an edge bulges it and pulls out.
Pressing through powder cracks the coating.
We buy the equal part we stock and say so on the quote.
A hardware and assembly package we can price in a day.
